FEATURES︰

1.Complete one cycle of automatic spindle operation started with push button.

2.Built-in air hydro checker system,converting air to hydraulic pressure.

3.Constant quill drive, directly by cylinder pressure.

4.High repeatability of drill depth with timer. (option)

5.Easy stroke adjustment. 6.Mroe high productivity with multi-spindle head or special purpose machine

● 用附帶之旋鈕來調整切削速度，全行程和快速進刀衝程，設定非常簡單，只須依照刻度設定行程，設定一次就能夠重複地作同樣的加工。

● 設定快速進刀衝程為50mm，全行程80mm的狀態，故快速進刀衝成為50mm，切削行程就變成30mm。亦可裝置多軸器。
